Black 11X11 Mesh SS316 Stainless Steel Security Screens Fly Proof Wire Mesh
Stainless Steel Security Mesh Introduction
Stainless Steel Security Mesh mainly are used for window and doors. they are designed to protect your family, allow air-flow and look amazing on your home. security screens are made of high-strength 304 316 stainless steel wire. It can not only block insects and mosquitoes, but also block thieves from entering the window. They can’t be cut (with a knife), kicked-in or pried open.
Besides, Our Stainless Steel Security Mesh have very bright and smooth surface, it is anti dust and very easy to clean.
Stainless Steel Security Mesh: black, grey, white or brown, etc
Stainless Steel 304 and 316:
The main difference between 304 vs 316 stainless steel is that 304 does not contain molybdenum, while 316 contains 2-3% molybdenum and less chromium and more nickel. The addition of molybdenum provides pitting resistance in phosphoric acid, acetic acid and dilute chloride solutions and provides corrosion resistance in sulfurous acid. AISI 304 has a 18% Cr and 8% Ni and therefore known as 18/8 stainless steel, while AISI 316 stainless steel has a 16% Chromium and 10% Nickel.
SUS316 and 304 comparation:
| 304 vs 316 Composition (%) |
| Stainless Steel | C, ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Cr | Ni | Mo |
| 304 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-11.0 | – |
| 316 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| 304L | 0.03 | 1.00 | 2.00 | 0.035 | 0.030 | 18.0-20.0 | 8.0-12.0 | – |
| 316L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
Stainless Steel Security Mesh Specification
| Material | Mesh Count | Wire Dia mm / inch | Open (mm) |
| SS 316 or 304 | 10 x 10 | 0.90mm /0.035" | 1.64 |
| SS 316 or 304 | 10 x 10 | 1.20mm /0.028" | 1.34 |
| SS 316 or 304 | 10 x 10 | 0.80mm / 0.032" | 1.74 |
| SS 316 or 304 | 10 x 10 | 1.15mm / 0.045" | 1.39 |
| SS 316 or 304 | 11 x 11 | 0.80mm /0.032" | 1.50 |
| SS 316 or 304 | 11 x 11 | 0.70mm / 0.027" | 1.60 |
| SS 316 or 304 | 12 x 12 | 0.70mm / 0.027" | 1.42 |
| SS 316 or 304 | 12 x 12 | 0.58mm / 0.023" | 1.54 |
| SS 316 or 304 | 13 x 13 | 0.60mm / 0.024" | 1.35 |
| SS 316 or 304 | 14 x 14 | 0.50mm / 0.020" | 1.31 |
| SS 316 or 304 | 16 x 16 | 0.45mm / 0.018" | 1.14 |
Stainless Steel Security Mesh Sheets Main Size:
Width x Length
750mm x 2000mm / 2400mm / 3000mm / 3500mm
900mm x 2000mm / 2400mm / 3000mm / 3500mm
1000mm x 2000mm / 2400mm / 3000mm / 3500mm
1200mm x 2000mm / 2400mm / 3000mm / 3500mm
1500mm x 2000mm / 2400mm / 3000mm / 3500mm
For other size, we can custom too.
Stainless steel security mesh before powder coated
Stainless steel security mesh after powder coated
Stainless Steel Security Mesh Sheets are installed on Door window Frame:
Company Profile
Anping Jiufu Metal Wire Mesh Co.,ltd is a premier manufacturer and supplier of wire mesh products located in Anping Town, thefamous Wire Mesh Land of China. We have engaged in wire drawing, wire mesh weaving and metal fabricating for about 20 years and have accumulated rich experiences in this field.
Our Products:
Jiufu offers the following special alloy wire mesh and filter products with experienced technology and good quality: Stainlesssteel wire mesh, duplex stainless steel wire mesh, nickel wire mesh, molybdenum wire mesh, pure silver wire mesh, copper wire mesh, soap cage, wire mesh basket, coffee filter, smoking pipe screen, filter tube and so on.
Our Advantage
Jiufu has the expertise, the technical force, the advanced processing and inspection equipment, and the experience to establish good business relationship with world customers. Jiufu has adopted modern management system to ensure product quality and reasonable price.
Main Market
Most of our wire mesh products are for export to Europe, the United States, the Middle East, Southeast Asia, and many
other countries and regions.Welcome to contact us.
FAQ
Q:Are you factory/manufacturer or trader?
A:We are direct factory who owns production lines and workers.
Q:Do you provide samples?is it free or extra?
A:Of course yes,we could offer the stock sample for free charge .
Q:Which payment method you can accept?
A:Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of shipping documents. Other payment term. we can also discuss.
Q:How to make a inquiry of Aluminum wire mesh?
A:You need to provide material,mesh number, wire diameter,size and the quantity to ask an offer, you can also indicate if you have
any special requirement. We'll providea formal quotatiom list after your inquiry received.
Q:What is your minimum order quantity?
A:Actually there is no MOQ for our products. But usually we recommend a quantity based on the price which is easy to accept.
